Model Toggle Lever in FreeCAD

Hello friends welcome to FreeCAD tutorial in our previous tutorial we have learned Model Locating Finger in FreeCAD In this tutorial we will do Model Toggle Lever with the help of Part design workbench of FreeCAD. You can also download my source file of the tutorial at https://www.mechnexus.com/mechnexus-youtube-tutorial-source-file/ so let’s start our tutorial.

Freecad Ad 01

Also Read-:

FreeCAD Part Modeling Tutorial 52
FreeCAD Part Modeling Tutorial 53
FreeCAD Part Modeling Tutorial 54



TG00

TG00_00

Select the XZ plane and create the below profile.

TG01

Now extrude the profile to distance of 25.58 and keep it to symmetric to plane.

TG02

Now select the bottom face and create the below profile.

TG03

Now remove the material as shown in below image.

TG04

Now select the front face and create the shown profile

image_2023-09-19_153719958

Now remove the material to 6mm as shown in the below image.

image_2023-09-19_153820242

Now use the mirror tool and mirror the feature.

image_2023-09-19_153921105

Now Select the face and create the circle of dia. 12.75mm

image_2023-09-19_154021894

Remove the material as shown.

image_2023-09-19_154121905
