Model Locating Finger in FreeCAD

Hello friends welcome to FreeCAD tutorial in our previous tutorial we have learned List of Supported File Formats in FreeCAD. In this tutorial we will model Locating Finger with the help of Part design workbench of FreeCAD. You can also download my source file of the tutorial at https://www.mechnexus.com/mechnexus-youtube-tutorial-source-file/ so let’s start our tutorial.

Freecad Ad 01

Also Read-:

Model Chuck Jaw in FreeCAD
Model Frame Guide in FreeCAD
Model Cut-off Holder in FreeCAD

Locating Finger

Locating Finger_01

Select XY plane and create the below sketch.

L01

Now extrude the above sketch to 14mm as shown in below image.

L02

Now select the mid plane and create the below profile.

L03

Noe extrude the above profile to distance of 54 mm and keep it symmetric to plane as shown in below image.

L04

Now select the back face and create the below profile.

L05

Now with Pocket tool remove the material set tit to Through All.

L06

Now select the top face and create below profile to create the hole.

L07

Now create the Hole as shown in below image.

L08

Now again select the top face and create the below profile.

L09

Now create the hole as shown in below image.

L10

Now select the front two edges and give chamfer of 13 mm.

L11
