FreeCAD Part Modeling Tutorial 61

Hello Friends in last tutorial we have learned How to model Sheet metal tray in FreeCAD with the help the help of dynamic data addon. In this tutorial we will do part modeling with the help of part design workbench.

Freecad Ad 01

Exploring FreeCAD Macros and Python Scripting
FreeCAD as An Open-Source Parametric 3D Modeling Software
How to Import and Export Files in FreeCAD

FreeCAD Part Modeling Tutorial 61

FreeCAD Part Modeling Tutorial 61_01

First select the front plane and create the sketch profile as shown in below image.

61_01

Now extrude to the length of 30mm as shown in below image.

61_02

Now select the face and create the profile as shown in below image.

61_03

Remove the material completely as shown in below image.

61_04

Now select the face and create below profile.

61_05

Now Extrude to the length of 50mm as shown in below image.

61_06

Now create a Datum plane at distance of -6 from the face.

61_07

Now on Datum plane create below profile.

61_08

Now create pad of 5mm of created profile.

61_09

Now select the face and create a circle as shown in below image.

61_10
