Model Mounting Bracket in FreeCAD

Hello friends welcome to FreeCAD tutorial in our previous tutorial we have learned Model Control Guide in FreeCAD. In this tutorial we will do modeling of Mounting Bracket with the help of Part design workbench of FreeCAD. You can also download my source file of the tutorial at https://www.mechnexus.com/mechnexus-youtube-tutorial-source-file/ so let’s start our tutorial.

Freecad Ad 01

Also Read-:

Model Index Slide in FreeCAD
Model Chuck Jaw in FreeCAD
Model Frame Guide in FreeCAD

Mounting Bracket R1

Mounting Bracket R2

Now select the top plane and create below sketch.

Mounting Bracket 01

Now extrude the above sketch to 10mm.

Mounting Bracket 02

Now select the back face and create the below sketch.

Mounting Bracket 03

Now create the cut of 10mm as shown in below image.

Mounting Bracket 04

Now select the back face and create below profile.

Mounting Bracket 05

Now create the pad of 10mm as shown in below image.

Mounting Bracket 06

Now project the arc and create hole sketch as shown in below image.

Mounting Bracket 07

Now create the hole as shown.

Mounting Bracket 08
